Motorola ATS 3000

6816985H01-F February 14, 2012
Troubleshooting Waveforms: Main Circuit Board RF Shield Locations 7.5-5
Viewed from Side 2
Table 7.5-4. Main Circuit Board Side 2 RF Shields
Item
Number
Reference
Number
Motorola Part
Number
Description
1 SH1 2616071H01 Shield, Mixer
2 SH402 2616518H01 Shield, 2nd LO
3 SH202 2616556H01 Shield, Frac-N
4 SH102 2616557H01 Shield, Harmonic Bottom
5 SH101 2616559H01 Shield, PCIC
6 SH203 2616553H01 Shield, VCO Bottom
7 SH2 2616550H01 Shield, Crystal IF
1
2
7
4
5
6
3
MAEPF-27488-O
