6816985H01-F February 14, 2012
700/800 MHz Troubleshooting Waveforms: Main Circuit Board RF Shield Locations 7.4-5
Viewed from Side 2
Table 7.4-4. Main Circuit Board Side 2 RF Shields
Item
Number
Reference
Number
Motorola Part
Number
Description
1 SH1 2685090D01 Shield, Mixer
2 SH402 2685080D01 Shield, 2nd LO
3 SH202 2685088D01 Shield, Frac-N
4 SH102 2685084D01 Shield, Harmonic Bottom
5 SH101 2685082D01 Shield, PCIC
6 SH203 2685087D01 Shield, VCO Bottom
7 SH2 2685242D01 Shield, Crystal IF
1
2
7
4
5
6
3
MAEPF-27488-O
