6816985H01-F February 14, 2012
700/800 MHz Troubleshooting Waveforms: PP2 TX Signal at Harmonic Filter Input 7.4-7
7.4.6 PP2 TX Signal at Harmonic Filter Input
Probe point: C105 (located under shield).
