February 14, 2012 6816985H01-F

8.4-8 700/800 MHz Troubleshooting Tables: Tables

J5 MAKO_INT* MAKO_INT

(Test Point)

Yes

J4 OPT_SEL1 U201 pin 1 Yes

J3 NOT USED No

C16 CODEC_FSYNC SYNC 8 KHz Pulse Yes

G11 OPT_SEL2_IN U601 pin 1 Yes

F1 KEYPAD_ROW0 J601, pin 16 Yes

H4 KEYPAD_ROW1 J601, pin 17 Yes

H6 KEYPAD_ROW2 J601, pin 18 Yes

G2 KEYPAD_ROW3 J601, pin 19 Yes

G11 KEYPAD_ROW4 J601, pin 20 Yes

G7 KEYPAD_ROW5 J601, pin 21 Yes

H7 KEYPAD_ROW6 J601, pin22 Yes

H1 UCM_SPARE1 J601, pin 39 Yes

D1 KEYPAD_COL0 J601, pin 23 Yes

G5 KEYPAD_COL1 J601, pin 24 Yes

F3 KEYPAD_COL2 J601, pin 25 Yes

G4 ENC_RESET J601, pin 42 Yes

F2 BOOT* No

E1 WAKEUP J601, pin 6 Yes

H6 SPARE2_ENC J601, pin 44 Yes

G3 NOT USED No

E7 NOT USED No

A8 HAB_MOD No

F8 MISOA_SEL Q801, pin 1 Data Line Yes

E8 SB3 R510 Yes

G8 SB2 R509 Yes

C3 SB1 R508 Yes

D4 LOCK_DET C123 Active Low Yes

A2 NOT USED No

B2 RTA3 VR596, pin 2 Yes

Table 8.4-5. Patriot MCU/DSP (U800) Pinout (Continued)

U401

Pin Number

Description To/From Comment

Accessible on

Main Board?
