February 14, 2012 6816985H01-F
8.5-10 900MHz Troubleshooting Tables: Tables
C11 TX_SSI_CLK R259 1.536 MHz Yes
B10 RED_LED Q501, pin 3 Active High Yes
D10 GREEN_LED Q501, pin 5 Active High Yes
B11 TX_SSI_FSYNC R251 48 KHz Yes
J10 CODEC_TX TX MAKO to DSP
Tx Audio Data
Yes
J15 CODEC_DCLK DCLK 512 KHz Yes
K16 CODEC_FSYNC SYNC 8 KHz Pulse Yes
D7 MISOA U801, pin 4 SPI A Data
Out
Yes
D3 MISOB BMISO SPI B Data
Out
Yes
E6 NOT USED No
F7 NOT USED No
D6 NOT USED No
C5 NOT USED No
A9 NOT USED No
B8 NOT USED No
B9 NOT USED No
A10 NOT USED No
G6 BT_DISABLE No
D13 NOT USED No
S15 BT_WAKE No
F11 RX_SSI_CLK SSI_CK Yes
B15 OPT_SEL2_OUT R666 Yes
J13 NOT USED Yes
J16 NOT USED Yes
J12 NOT USED Yes
H11 NOT USED Yes
A5 GROUND GROUND No
N6 GROUND GROUND No
P8 GROUND GROUND No
Table 8.5-5. Patriot MCU/DSP (U800) Pinout (Continued)
U401
Pin Number
Description To/From Comment
Accessible on
Main Board?
To Next Page
