Motorola ATS 3000

9.1-58 VHF Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R757 0613952R08 CER CHIP RES 20K OHM 5
0402
R758 0613952R19 CER CHIP RES 56K OHM 5%
0402
R759 0613952R01 CER CHIP RES 10K OHM 5%
0402
R760 0613952Q93 CER CHIP RES 6800 OHM 5
0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R768 NOT PLACED –
R771 NOT PLACED –
R772 0613952Q49 CER CHIP RES 100 OHM 5
0402
R773 0613952Q49 CER CHIP RES 100 OHM 5
0402
R774 0613952Q49 CER CHIP RES 100 OHM 5
0402
R775 0613952Q49 CER CHIP RES 100 OHM 5
0402
R776 NOT PLACED –
R777 0613952R01 CER CHIP RES 10K OHM 5%
0402
R778 0613952R01 CER CHIP RES 10K OHM 5%
0402
R779 0613952R01 CER CHIP RES 10K OHM 5%
0402
R780 0613952Q89 CER CHIP RES 4700 OHM 5
0402
R781 0613952R01 CER CHIP RES 10K OHM 5%
0402
R782 0613952R01 CER CHIP RES 10K OHM 5%
0402
R783 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R784 NOT PLACED –
R785 0613952Q49 CER CHIP RES 100 OHM 5
0402
R786 0613952R17 CER CHIP RES 47K OHM 5%
0402
R790 0613952R19 CER CHIP RES 56K OHM 5%
0402
R791 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R792 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R793 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R794 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R795 0613952R17 CER CHIP RES 47K OHM 5%
0402
R796 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R797 0613952Q41 CER CHIP RES 47.0 OHM 5
0402
R798 0613952Q61 CER CHIP RES 330 OHM 5
0402
R799 0613952R01 CER CHIP RES 10K OHM 5%
0402
R801 NOT PLACED –
R802 0613952Q49 CER CHIP RES 100 OHM 5
0402
R803 0613952Q49 CER CHIP RES 100 OHM 5
0402
R804 0613952Q66 CER CHIP RES 510 OHM 5
0402
R805 0613952R01 CER CHIP RES 10K OHM 5%
0402
R806 0613952Q66 CER CHIP RES 510 OHM 5
0402
R807 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R808 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R809 0613952R17 CER CHIP RES 47K OHM 5%
0402
R810 0613952R01 CER CHIP RES 10K OHM 5%
0402
R811 0613952Q66 CER CHIP RES 510 OHM 5
0402
R812 0613952R25 CER CHIP RES 100K OHM 5%
0402
R813 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R814 NOT PLACED –
R815 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R816 0613952R17 CER CHIP RES 47K OHM 5%
0402
R820 0613952R01 CER CHIP RES 10K OHM 5%
0402
R829 NOT PLACED –
R837 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R838 0613952Q37 CER CHIP RES 33.0 OHM 5
0402
R839 0613952R01 CER CHIP RES 10K OHM 5%
0402
R840 0613952Q66 CER CHIP RES 510 OHM 5
0402
R841 0613952R01 CER CHIP RES 10K OHM 5%
0402
R842 0613952R01 CER CHIP RES 10K OHM 5%
0402
R843 0613952R41 CER CHIP RES 470K OHM 5%
0402
R844 0613952Q61 CER CHIP RES 330 OHM 5
0402
S500 4085131E04 SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06 POTENTIOMETER, VOLUME
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
S502 4016882H01 TACTILE SWITCH
EMERGENCY
S503 4070354A01 LIGHT TOUCH SWITCH-SMD
S504 4070354A01 LIGHT TOUCH SWITCH-SMD
S505 4070354A01 LIGHT TOUCH SWITCH-SMD
S506 4070354A01 LIGHT TOUCH SWITCH-SMD
SH1 2686707Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH51 2686700Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH52 2686699Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH101 2686702Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH102 2686701Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH103 2686708Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH201 2686705Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH251 2616554H01 SHLD VCO TOP
SH252 2616559H01 SHLD PCIC
SH401 2686706Z02 SHIELD, SM
SLDRD,CRS,PLTD
SH402 2686698Z02 SHIELD, SM
SLDRD,CRS,PLTD
T51 2515121H01 BALUN, TRANSFORMER W18
COMP
T53 2516320H01 XFMR SMALL SIGNAL
SURFACE MT
U1 5164015H81 IC,MXR,DBL BAL GILBERT,
CELL,SM
U2 5185941F45 ATTEN,VAR,14.4DBMIN,15.6D
BMAX,0-2000 MHZ-
FREQ,50OHM,PCMT,SOT
U3 5116349H01 DUAL INVERTER IC
U101 51012101001 VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
