Motorola ATS 3000

UHF1 Schematics, Board Overlays, and Parts Lists 9.2-67
6816985H01-F February 14, 2012
R711 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R712 0613952Q49 CER CHIP RES 100 OHM 5
0402
R714 0688044N04 RES,METAL STRIP, 0.1
OHM,1%, 0.125W,SMD,0805,7
R717 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R718 0613952G67 CER CHIP RES 0.0 +/-0.050
OHM
R722 0613952R08 CER CHIP RES 20K OHM 5
0402
R725 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R726 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R729 0613952R13 CER CHIP RES 33K OHM 5%
0402
R740 0613952Q63 CER CHIP RES 390 OHM 5
0402
R741 0613952R17 CER CHIP RES 47K OHM 5%
0402
R742 0613952R17 CER CHIP RES 47K OHM 5%
0402
R743 NOT PLACED –
R744 NOT PLACED –
R745 0613952R56 CER CHIP RES 2.0M OHM 5
0402
R746 0613952R56 CER CHIP RES 2.0M OHM 5
0402
R747 0613952Q73 CER CHIP RES 1000 OHM
5 0402
R748 0613952R41 CER CHIP RES 470K OHM 5%
0402
R749 0613952R41 CER CHIP RES 470K OHM 5%
0402
R750 0613952Q63 CER CHIP RES 390 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R751 0613952Q63 CER CHIP RES 390 OHM
5 0402
R752 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R753 0613952Q81 CER CHIP RES 2200 OHM
5 0402
R756 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R757 0613952R08 CER CHIP RES 20K OHM
5 0402
R758 0613952R19 CER CHIP RES 56K OHM 5%
0402
R759 0613952R01 CER CHIP RES 10K OHM 5%
0402
R760 0613952Q93 CER CHIP RES 6800 OHM
5 0402
R763 NOT PLACED –
R764 NOT PLACED –
R765 NOT PLACED –
R767 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R768 NOT PLACED –
R771 NOT PLACED –
R772 0613952Q49 CER CHIP RES 100 OHM
5 0402
R773 0613952Q49 CER CHIP RES 100 OHM
5 0402
R774 0613952Q49 CER CHIP RES 100 OHM
5 0402
R775 0613952Q49 CER CHIP RES 100 OHM
5 0402
R776 NOT PLACED –
R777 0613952R01 CER CHIP RES 10K OHM 5%
0402
R778 0613952R01 CER CHIP RES 10K OHM 5%
0402
R779 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R780 0613952Q89 CER CHIP RES 4700 OHM
5 0402
R781 0613952R01 CER CHIP RES 10K OHM 5%
0402
R782 0613952R01 CER CHIP RES 10K OHM 5%
0402
R783 0613952R01 CER CHIP RES 10K OHM 5%
0402
R784 NOT PLACED –
R785 0613952Q49 CER CHIP RES 100 OHM
5 0402
R786 0613952R17 CER CHIP RES 47K OHM 5%
0402
R790 0613952R19 CER CHIP RES 56K OHM 5%
0402
R791 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R792 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R793 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R794 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R795 0613952R17 CER CHIP RES 47K OHM 5%
0402
R796 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R797 0613952Q41 CER CHIP RES 47.0 OHM
5 0402
R798 0613952Q61 CER CHIP RES 330 OHM 5
0402
R799 0613952R01 CER CHIP RES 10K OHM 5%
0402
R801 NOT PLACED –
R802 0613952Q49 CER CHIP RES 100 OHM
5 0402
R803 0613952Q49 CER CHIP RES 100 OHM
5 0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R804 0613952Q66 CER CHIP RES 510 OHM
5 0402
R805 0613952R01 CER CHIP RES 10K OHM 5%
0402
R806 0613952Q66 CER CHIP RES 510 OHM
5 0402
R807 0613952R01 CER CHIP RES 10K OHM 5%
0402
R808 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R809 0613952R17 CER CHIP RES 47K OHM 5%
0402
R810 0613952R01 CER CHIP RES 10K OHM 5%
0402
R811 0613952Q66 CER CHIP RES 510 OHM
5 0402
R812 0613952R25 CER CHIP RES 100K OHM 5%
0402
R813 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R814 NOT PLACED –
R815 0613952R66 CER CHIP RES 0.0 +/-0.050
OHM
R816 0613952R17 CER CHIP RES 47K OHM 5%
0402
R820 0613952R01 CER CHIP RES 10K OHM 5%
0402
R829 NOT PLACED –
R837 0613952Q37 CER CHIP RES 33.0 OHM
5 0402
R838 0613952Q37 CER CHIP RES 33.0 OHM
5 0402
R839 0613952R01 CER CHIP RES 10K OHM 5%
0402
R840 0613952Q66 CER CHIP RES 510 OHM 5
0402
R841 0613952R01 CER CHIP RES 10K OHM 5%
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
