Motorola ATS 3000 User Manual

9.4-24 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
PMLF4040A/ PMLF4040B/ PMUF2134A/
PMUF2123A/PMUF2135A/PMUF2124A/
PMUF3334A/PMUF3323A/PMUF3335A/
PMUF3324A
Main Circuit Board
Electrical Parts List
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
B500 0986237A02
CONNECTOR (CONTACT
BATTERY)
C1 2113944A30 27PF
C2 2113944A32 39PF
C3 NOT PLACED –
C4 2113944A42 150PF
C5 2113944A21 6.8PF
C6 2113946F03 4.7UF
C7 2113944A32 39PF
C8 2113944A32 39PF
C9 2113944A32 39.0PF
C11 2113945B05 0.033UF
C12 2113944A32 39PF
C13 2113944A32 39PF
C14 NOT PLACED –
C15 2113944A32 39PF
C16 2113944A33 47PF
C17 2113944A08 2PF
C18 2113944A01 1.1PF
C19 2113944C67 1.5PF
C20 2113944A09 2.2PF
C22 2113944A32 39PF
C23 2113945B05 0.033UF
C25 2113945B05 0.033UF
C26 2113944A32 39PF
C27 2113945B05 0.033UF
C28 2113946F03 4.7UF
C29 2113944A36 68PF
C31 2113945B05 0.033UF
C33 2113946F03 4.7UF
C35 2113944A33 47PF
C36 2113944A70 6PF
C37 2113944A32 39PF
C101 2113944C37 39PF
C103 2113944C61 0.5PF
C104 2113944C67 1PF
C105 2113944C13 2PF
C106 2113944C13 2PF
C107 2113944C63 1PF
C108 2113944C67 1PF
C109 NOT PLACED –
C110 2113944A32 39PF
C111 2113944C37 39PF
C116 2113944C61 0.5PF
C117 2113944C63 1PF
C118 2113944A77 11PF
C119 2113946K02 0.10UF
C120 2113944C37 39PF
C121 2113944M28 27PF
C122 2113946K02 0.10UF
C123 2113944A32 39PF
C125 2113945L49 0.01UF
C127 2103689A32 1.5PF
C128 2103689A08 18PF
C129 2116636H05 0.5PF
C130 2113946K02 0.10UF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C132 2113944A40 100PF
C133 2113944A77 11PF
C134 2113944M25 20PF
C136 2113946K02 0.10UF
C137 2113944A32 39PF
C139 2113946K02 0.10UF
C140 2113944C31 12PF
C141 NOT PLACED –
C142 2116069H01 27PF
C144 2113944A32 39PF
C145 2113945B02 10000PF
C146 2113944A32 39PF
C147 2113946K02 0.10UF
C148 2113945B02 10,000PF
C149 2113944A24 9.1PF
C151 2113944A32 39PF
C152 2113944A32 39PF
C153 2113944A32 39PF
C154 2113944A32 39PF
C156 2113945A07 680PF
C157 2113945A07 680PF
C158 2113945B02 10,000PF
C159 2113944A32 39PF
C160 2113944A32 39PF
C161 2113944A32 39PF
C162 2113946K02 0.10UF
C163 2113944A32 39PF
C164 2113946K02 0.10UF
C165 2113944A32 39PF
C166 2113946K02 0.10UF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C168 2313960C26 1.0 UF
C169 2113944A77 11PF
C200 2113946K02 0.10UF
C201 2113946N03 2.2UF
C202 2113945B02 10000PF
C203 2113945B02 10000PF
C204 2113945B02 10000PF
C205 2113945B02 10000PF
C206 2113944A31 33PF
C207 2313960D07 10UF
C208 2313960D07 10UF
C209 2113946K02 0.10UF
C210 2113945B02 10000PF
C211 NOT PLACED –
C212 2113946K02 0.10UF
C213 2113946K02 0.10UF
C214 2113946N03 2.2UF
C215 2113946K02 0.10UF
C216 2113944A31 33PF
C217 2113946N03 2.2UF
C218 2185419D06 0.1UF
C219 2113946K02 0.1UF
C220 2113944A31 33PF
C221 2185419D06 0.1UF
C222 2113944A31 33PF
C223 2113945A01 220PF
C224 2113946K02 0.1UF
C225 2113946K02 0.1UF
C226 2113944A31 33PF
C227 2113946K02 0.1UF
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
