Motorola ATS 3000 User Manual

700/800 MHz Schematics, Board Overlays, and Parts Lists 9.4-35
6816985H01-F February 14, 2012
C851 2113944A40 100 PF
C855 NOT PLACED –
C856 NOT PLACED –
C857 NOT PLACED –
C858 2113945B02 10,000PF
C859 2113945B02 10,000PF
C860 2113945B02 10,000PF
C861 2113945B02 10,000PF
C862 2113945B02 10,000PF
C863 2113945B02 10,000PF
C864 2113945B02 10,000PF
C865 2113945B02 10,000PF
C866 2113945B02 10,000PF
C867 NOT PLACED –
C868 NOT PLACED –
CR101 4815897H01 PIN DIODE
CR102 4815897H01 PIN DIODE
CR800 4813978A25 DIODE,
CR801 4813978A25 DIODE
D1 4813974A19 DIODE
D103 4813974A05 DIODE
D104 4816487H01 SWITCHING DIODE
D201 4815011H01 DIODE
D202 4815011H01 DIODE
D210 4805656W87 DIODE
D211 4805656W87 DIODE
D212 4805656W87 DIODE
D401 4815096H01 VARACTOR DIODE 1SV305
D402 4885055Y01 DIODE VARACTOR PB-FREE
D501 4809118D02 LED
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
D510 NOT PLACED –
D511 4813978M15 DIODE
D600 4813978B18 DIODE
D603 4813978A25 DIODE
D662 4813978A25 DIODE
D700 4813978B18 DIODE
E101 2415954H01 INDUCTOR BEAD CHIP
E102 2405688Z01 INDUCTOR FERRITE BEAD
E401 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E402 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E403 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E404 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E405 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E406 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E407 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E408 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E409 2480640Z01
SURFACE MOUNT FERRITE
BEAD
E500 2405688Z01 INDUCTOR FERRITE BEAD
E501 2405688Z01 INDUCTOR FERRITE BEAD
E800 2480574F01
IND FERRITE CHIP 60OHM
0603
E801 2480574F01
IND FERRITE CHIP 60OHM
0603
E802 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
F500 6515076H01
FUSE CHIP SMT TR/1608FF
3A
FL1 9116647H01
LC FLTR, MULITILAYER
CERAMIC
FL2 9116647H01
LC FLTR, MULITILAYER
CERAMIC
FL3 4885631B01
XTAL FILT 3 POLE 109.65
MOTORO
FL200 9116848H01
FLTR SW CAP 3 POLE
BUTTERW, W18
J101 2880658Z08 CONNECTOR, SMA
J601 0916287H01 CONN VERT 45 PIN ZIF
J650 0916287H02 CONN 20 PIN ZIF
L1 2414017G19 100NH
L2 2415429H33 CHIP INDUCTOR
L4 2488090Y14 12NH
L5 2488090Y12 8.2NH
L6 2488090Y14 12NH
L7 NOT PLACED –
L10 2415429H32 CHIP INDUCTOR
L11 2414017N22 68NH
L12 2414032F40 330NH
L13 2414032F42 470NH
L14 2414032F38 220NH,
L15 NOT PLACED –
L16 2415429H43 CHIP INDUCTOR
L101 2414032F36 150NH
L102 NOT PLACED –
L103 2460591D24
COIL AIR WOUND INDUC
19.61
L104 2460591A11 COIL AIR WOUND INDUC 7.66
L106 0613952G67 RES 0.0 OHM
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
L107 2414017G19 100NH
L108 2414017G18 82NH
L109 2460591B22 COIL AIR WOUND INDUC 8.67
L110 2414017G05 6.8NH
L111 2414017G18 82NH
L112 2414017G12 27NH
L113 2415428H03 AIR WOUND INDUCTOR
L114 2460591A11 COIL AIR WOUND INDUC 7.66
L200 2414017Q20 2.2UH
L201 2414017Q20 2.2UH
L203 2414017Q47 1UH
L204 2414032F21 6.8NH
L205 2414017Q20 2.2UH
L210 2414032F36 150NH
L211 2414032F36 150NH
L212 2414032F36 150NH
L214 2414032F36 150NH
L215 2414032F36 150NH
L216 2414032F36 150NH
L217 2414032F36 150NH
L218 2414032F36 150NH
L219 2414032F36 150NH
L220 2414032F26 22NH
L221 2414032F24 15NH
L230 2414032F25 18NH
L290 2414017Q47 1UH
L299 NOT PLACED –
L401 2414032D17 150NH
L402 2466505A01 COIL INDUCTOR
L403 2466505A01 COIL INDUCTOR
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
