Motorola ATS 3000

9.4-46 700/800 MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
Q214 4813972A15
PB-FREE,NOT COMPLETELY
ENRICHED
Q215 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q216 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q217 4813972A15
PB-FREE,NOT COMPLETELY
ENRICHED
Q218 4813972A15
PB-FREE,NOT COMPLETELY
ENRICHED
Q401 4805585Q27
TRANSISTOR RF NPN,
BFQ67W NOPB
Q501 4805921T28 XSTR, DUAL NOPB
Q698 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
Q700 4813970A62
XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,PB-
FREE
Q701 4813973M07
XSTR,BIP GP SS,NPN,T3904,
SM,SOT-23,SMT,40V,.225W,
200MA,300MHZ
Q702 5185956E76
IC,CONV,SM,SO16,0-30
VINPUT RANGE,6.5A,3.8V,HI
SPD SWTH DR
Q703 4813970A62
XSTR,FET GP PWR,MOSFET,
P-CH,ENHN,CF,-20V,1.3W,PB-
FREE
Q704 NOT PLACED –
Q705 NOT PLACED –
Q706 NOT PLACED –
Q709 4885061Y01
XSTR NPN 6V 30UA 12GHZ
PB-FREE
Q801 4813973A42
XSTR,BIP GP SS,NPN,SM,SC-
59,SMT,50V,.23W,100MA,PB-
FREE
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
Q804 4813973A81
XSTR,BIP GP SS,DIG,NPN
AND PNP,SOT-363,50V,.25W,
100MA,PB-FR
R1 0613952Q66
CER CHIP RES 510 OHM 5
0402
R2 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R3 0613952Q89
CER CHIP RES 4700 OHM 5
0402
R4 0613952Q83
CER CHIP RES 2700 OHM 5
0402
R5 0613952Q58
CER CHIP RES 240 OHM 5
0402
R7 0613952Q39
CER CHIP RES 39.0 OHM 5
0402
R10 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R11 0613952Q37
CER CHIP RES 33.0 OHM 5
0402
R20 NOT PLACED –
R30 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R40 0613952G67
CER CHIP RES 0.0 +/-0.050
OHM
R100 0613952H53
CER CHIP RES 150 OHM 5%
0603
R101 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R103 0613952H53
CER CHIP RES 150 OHM 5%
0603
R104 0613952Z22
FOR LEGACY LEAD-FREE
CONVERSION ONLY
R105 0613952H42
CER CHIP RES 51.0 OHM 5%
0603
R106 0613952H53
CER CHIP RES 150 OHM 5%
0603
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R107 0613952H63
CER CHIP RES 390 OHM 5
0603
R108 0613952R04
CER CHIP RES 13K OHM 5
0402
R109 0613952Q80
CER CHIP RES 2000 OHM 5
0402
R110 0613952R15
CER CHIP RES 39K OHM 5%
0402
R111 NOT PLACED –
R113 NOT PLACED –
R114 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R115 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R117 0613952R25
CER CHIP RES 100K OHM 5%
0402
R118 0613952R32
CER CHIP RES 200K OHM 5
0402
R119 0613952Q93
CER CHIP RES 6800 OHM 5
0402
R120 0613952Q53
CER CHIP RES 150 OHM 5
0402
R121 0613952H73
CER CHIP RES 1000 OHM 5%
0603
R200 0613952Q49
CER CHIP RES 100 OHM 5
0402
R201 0613952Q53
CER CHIP RES 150 OHM 5
0402
R202 0613952Q53
CER CHIP RES 150 OHM 5
0402
R204 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R205 0613952Q87
CER CHIP RES 3900 OHM 5
0402
R206 0613952Q48
CER CHIP RES 91.0 OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
R207 0613952Q57
CER CHIP RES 220 OHM 5
0402
R208 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R210 0613952Q73
CER CHIP RES 1000 OHM 5
0402
R211 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R212 0613952Q37
CER CHIP RES 33.0 OHM 5
0402
R213 0613952R66
CER CHIP RES 0.0 +/-0.050
OHM
R214 0613952R08
CER CHIP RES 20K OHM 5
0402
R215 0613952R19
CER CHIP RES 56K OHM 5%
0402
R216 0613952R17
CER CHIP RES 47K OHM 5%
0402
R217 0613952Q49
CER CHIP RES 100 OHM 5
0402
R220 0613952Q61
CER CHIP RES 330 OHM 5
0402
R221 0613952R18
CER CHIP RES 51K OHM 5
0402
R222 0613952Q25
CER CHIP RES 10.0 OHM 5
0402
R223 0613952R08
CER CHIP RES 20K OHM 5
0402
R224 0613952R08
CER CHIP RES 20K OHM 5
0402
R225 0613952Q37
CER CHIP RES 33.0 OHM 5
0402
R226 0613952Q17
CER CHIP RES 4.7 OHM 5
0402
R227 0613952R18
CER CHIP RES 51K OHM 5
0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
