Motorola ATS 3000

9.5-28 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
C298 2185419D06
CAP,CHIP,.1UF,+10%, -10%,
25V-DC
C401 2113955E37
CAPACITOR,FIXED,10UF,
+10%,-10%,16V-DC,1210
C402 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C403 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
C404 2113944C37
CAP CER CHP 39.0PF 50V 5%
C405 2113944A79
CAP,FXD,16PF,+5%, -5%,
50V-DC
C406 2113944A79
CAP,FXD,16PF,+5%, -5%,
50V-DC
C407 2113944A25
CAP CER CHP 10.0PF 50V +/-
0.5PF
C408 2113945B02
CAP CER CHP 10,000PF 25V
10%
C409 2113945L49
CAP,FXD,.01UF,+5%,-5%,
50V-DC,0604
C410 2113944A32
CAP CER CHP 39.0PF 50V 5%
C411 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C412 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C413 2113945B02
CAP CER CHP 10,000PF 25V
10%
C414 2113945B02
CAP CER CHP 10,000PF 25V
10%
C415 2113945L37
CAP,FXD,3300PF,+5%, -5%,
50V-DC,0603
C416 2189705V01
CAP,CER,.1UF,+5%,-5%,
50V-DC
C417 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603
C418 2113944A32
CAP CER CHP 39.0PF 50V 5%
C419 NOT PLACED
–
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C420 NOT PLACED
–
C421 2113945B02
CAP CER CHP 10,000PF 25V
10%
C422 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C423 2113944C01
CAP CER CHP 180.0PF 50V
5%
C424 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C425 2113945B02
CAP CER CHP 10,000PF 25V
10%
C426 2113944A40
CAP CER CHP 100.0PF 50V
5%
C427 2113944A40
CAP CER CHP 100.0PF 50V
5%
C428 2113945C31
CAP,FXD,.1UF,+10%, -10%,
5 0V-DC,0603
C429 2113945A11
CAP CER CHP 2200PF 50V
10%
C431 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603
C432 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603
C433 2113945C31
CAP,FXD,.1UF,+10%,-10%,
50V-DC,0603
C434 2113945B02
CAP CER CHP 10,000PF 25V
10%
C435 NOT PLACED
–
C436 NOT PLACED
–
C437 2113945B02
CAP CER CHP 10,000PF 25V
10%
C438 2113945B02
CAP CER CHP 10,000PF 25V
10%
C439 2113944A40
CAP CER CHP 100.0PF 50V
5%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C440 2113944A40
CAP CER CHP 100.0PF 50V
5%
C441 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C442 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C443 2113944A85
CAP,FXD,51PF,+5%, -5%,
50V-DC
C444 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C447 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C448 2113945C31
CAP,FXD,.1UF,+10%, -10%,
50V-DC,0603
C449 2113945B02
CAP CER CHP 10,000PF 25V
10%
C450 2113946G04
CAP,FXD,.68UF,+10%, -10%,
16V-DC,1206
C460 NOT PLACED
–
C461 2113945B02
CAP CER CHP 10,000PF 25V
10%
C500 2113944A32
CAP CER CHP 39.0PF 50V 5%
C501 2113944A32
CAP CER CHP 39.0PF 50V 5%
C502 2113944A32
CAP CER CHP 39.0PF 50V 5%
C503 2113944A32
CAP CER CHP 39.0PF 50V 5%
C504 2113945A11
CAP CER CHP 2200PF 50V
10%
C505 2113945G98
CAP,FXD,.47UF,+10%,
-10%,50V-DC,0805
C507 2113945B02
CAP CER CHP 10,000PF 25V
10%
C508 2113945B02
CAP CER CHP 10,000PF 25V
10%
C509 2113945B02
CAP CER CHP 10,000PF 25V
10%
C511 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
C513 2113955E37
CAPACITOR,FIXED,10UF,
+10%, -10%,16V-DC,1211
C514 2113955E37
CAPACITOR,FIXED,10UF,
+10%,-10%,16V-DC,1212
C516 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
C517 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
C518 2113946F03
CAP CER CHP 4.7UF 6.3V 10%
C519 2113944A40
CAP CER CHP 100.0PF 50V
5%
C520 2113944A32
CAP CER CHP 39.0PF 50V 5%
C550 2113945B02
CAP CER CHP 10,000PF 25V
10%
C552 2113945A01
CAP CER CHP 220PF 50V 10%
C553 2113945B02
CAP CER CHP 10,000PF 25V
10%
C554 2113945A11
CAP CER CHP 2200PF 50V
10%
C555 2113945A01
CAP CER CHP 220PF 50V 10%
C560 2113945B02
CAP CER CHP 10,000PF 25V
10%
C561 2113945B02
CAP CER CHP 10,000PF 25V
10%
C566 2113945B02
CAP CER CHP 10,000PF 25V
10%
C567 NOT PLACED
–
C590 NOT PLACED
–
C591 NOT PLACED
–
C592 NOT PLACED
–
C593 2113955E37
CAPACITOR,FIXED,10UF,
+10%,-10%,16V-DC,1214
C598 NOT PLACED
–
C599 NOT PLACED
–
C607 2113945Y02
CAP,FXD,.1UF,+10%, -10%,
16V-DC,0402
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
