Motorola ATS 3000

9.5-46 900MHz Schematics, Board Overlays, and Parts Lists
February 14, 2012 6816985H01-F
R842 0613952R01
CER CHIP RES 10K OHM 5%
0402
R843 0613952R41
CER CHIP RES 470K OHM 5%
0402
R844 0613952Q61
CER CHIP RES 330 OHM
5 0402
S500 4085131E04
SWITCH FREQ DUAL
FUNCTION
S501 1880619Z06
POTENTIOMETER, VOLUME
S502 4016882H01
TACTILE SWITCH
EMERGENCY
S503 4070354A01
LIGHT TOUCH SWITCH-SMD
S504 4070354A01
LIGHT TOUCH SWITCH-SMD
S505 4070354A01
LIGHT TOUCH SWITCH-SMD
S506 4070354A01
LIGHT TOUCH SWITCH-SMD
SH001 2616071H01
SHIELD MIXER
SH002 2616550H01
SHLD FITLER
SH101 2616559H01
SHLD PCIC
SH102 2616557H01
SHLD HARMONIC BOT
SH103 2616558H01
SHLD HARMONIC TOP
SH104 2616555H01
SHLD PA
SH201 2616560H01
SHLD SYN
SH202 2616556H01
SHLD FRAN N
SH203 2616553H01
SHLD VCO BOT
SH204 2616551H01
SHLD DAC
SH205 2616554H01
SHLD VCO TOP
SH401 2616552H01
SHLD ABACUS
SH402 2616518H01
SHLD 2ND LO FLTR
SH500 NOT PLACED
–
T1 2516149H01
XFMR JEDI MIXER 4:1
T2 2516372H01
TRANSFORMER, BALUN,
MIXER ,25:1
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
U1 5164015H81
IC,MXR,DBL BAL GILBERT,
CELL,SM
U101 51012101001
VHF/UHF/800/900 MHZ
LDMOS DRIVER IC
U102 5185765B26
IC PWR CTRL IN MOS20
U103 5115022H01
IC TEMPERATURE SENSOR
U106 5185368C84
DIRECTIONAL CPLR
7/800MHZ
U201 5116245H01
CC LVFRACN
U202 5185941F40
IC, 12 BIT DAC
U205 5116411H01
IC,OP AMP
U250 5171121L01
CUSTOM LOW VOLTAGE VCO
BUFFER IC
U401 5185963A85
IC-ABACUS III-LP
U500 5188493T01
IC,VREG/SWG,LP2989, SM,IC
MINI SO-8 HI PRCN REG 5V
U501 5185941F35
IC, VREG, NOPB
U502 5185941F35
IC, VREG, NOPB
U601 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U602 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U701 5185143E77
IC, MAKO ASIC, CMOS PWR
MGMT
U702 5185941F22
IC,OPAMP,SGL,OPA237,
SOT23,NOPB
U705 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U712 5188691V01
IC,MUX/DEMUX,
NC7SB3157P6X,SM,
SC70-6,1PER PKG, BUS,
PB FREE
U713 5115453H01
RAIL TO RAIL OUTPUT,
8 PIN BGA
U714 5115453H01
RAIL TO RAIL OUTPUT,
8 PIN BGA
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
U800 5185941F04
IC, PATRIOT BRAVO,
1.2.2,256BGA, PB-FREE
U801 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U802 5114000B39
IC,BFR,1PER PKG,SM,
SOT-353,PB-FREE
U803 51012093001
64MB,60NS,SM,1.8V,90NM
U804 5171897M01
IC,SRAM,8M,512KX16,55NS,S
M,FBGA48
U807 5185941F45
ATTEN,VAR,14.4DBMIN,
15.6DBMAX,0-2000 MHZ
FREQ,50OHM,PCMT
U809 5116349H01
DUAL INVERTER IC
VR500 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR501 4813977M19
DIODE,ZEN,MBZ5240,SM,
SOT-23,10V,10MA, .225W,
ZEN,PB-FREE
VR502 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR503 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR504 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR505 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR506 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR507 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR591 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR592 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
VR593 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR594 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR595 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR596 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR650 4813979P12
DIODE ARRAY,TRANSIENT
PROTECTION,SM, SOT-457,
12V,.225W, ZEN, 4,PB
VR651 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR652 4813977A43
PB-FREE, ZENER, SM, DUAL
5.6V COM ANODE, SOT23
T&R
VR657 4809788E21
DIODE, ZENER, SOD-323,
SMD, W18 COMPLIANT
VR658 4813977C23
DIODE,ZEN,MMSZ5243,SM,
SOD-123,13V,10MA,.5W, ZEN,
PB-FREE
VR659 4813979P10
DIODE ARRAY,TRANSIENT
PROTECTION,SM, SOT-457,
5.6V,.225W,ZEN, 4,P
VR662 4813979P10
DIODE ARRAY,TRANSIENT
PROTECTION,SM,S OT-457,
5.6V,.225W,ZEN, 4,P
VR663 4813977M18
DIODE,ZEN,MBZ5239,SM,
SOT-23,9.1V,10MA,.225W,
ZEN,PB-FREE
VR678 4866544A01
DIODE ARRAY,ZEN,
SR05.TCT,SM,5V,5,LOW
CAPACITANCE TVS DIO
ITEM
MOTOROLA
PART
NUMBER
DESCRIPTION
