MTR3000 Backplane: Description 6-21

Table 6-16 J1 Option 1 Connector, Row B Pins

Pin # Pin Assignment To/From

1 Spare A12 J2-B1

2 GND Station ground

3 5 VDC P8 pins 7, 8

4 Spare81 J2-B4, J5-B29

5 RF Relay Control Out J2-B5, J5-C9

6 RF Relay Control In J2-B6, J3-A24

7 Spare316 J2-B7, J5-B26

8 MISO P7-9, J2-B8, J3-B8, J4-B8

9 GND Station ground

10 Reserved –

11 OP1 CS1* J3-B11

12 Spare305 J5-B21

13 Spare A18 N/C

14 GND Station ground

15 14.2 VDC P8 pins 3, 4 (through F1)

16 Reset* J2-B16, J3-B16, J4-B16

17 Spare N/C

18 GND Station ground

19 Spare N/C

20 Reserved J2-B20, J3-B20, J4-B20

21 Spare N/C

22 Reserved –

23 Reserved –

24 Reserved –

25 Reserved –

26 Reserved –

27 Reserved –

28 Reserved –

29 Carrier Detect Switch J2-B29, J3-B24, J5-B4

30 GP2 OUT WCO J2-B30, J5-B3

31 Reserved –

32 Reserved –
