6-22 MTR3000 Backplane: Description
Table 6-17 J1 Option1 Connector, Row C Pins
Pin # Pin Assignment To/From
1 Spare A1 N/C
2 GND Station ground
3 5 VDC P8 pins 7, 8
4 Spare13 J2-C4, J3-A30
5 Spare314 J2-C5, J5-A29
6 Reserved –
7 Spare319 J2-C7, J5-A26
8 SPI CLK P7-7, J2-C8, J3-C8, J4-C8
9 GND Station ground
10 OP1 CS3* J3-C10
11 Spare J2-C11, J5-A22
12 Spare N/C
13 Spare N/C
14 GND Station ground
15 14.2 VDC P8 pins 3, 4 (through F1)
16 Spare N/C
17 Spare N/C
18 Spare N/C
19 Option1 ID J3-C18
20 Reserved J2-C20, J3-C20, J4-C20
21 GND Station ground
22 Reserved –
23 Reserved –
24 Reserved –
25 Reserved –
26 Reserved –
27 Reserved –
28 Reserved –
29 AC Fail P8-5, J2-C29, J3-C24, J5-A4
30 Spare N/C
31 Reserved –
32 Reserved –
