8-2 MTR3000 Wireline: Description
8.1.1.1 Input and Output Connections
Figure 8-1 shows the location of the Wireline board jumpers and all input and output external
connections.
Figure 8-1 Wireline Board Jumpers and Input/Output Connections
P8
Mates with Backplane
Interface Board
Jumpers
