1.9 Lifting the unit
WARNING
Risk of serious injury or death!
l
Only use rigging equipment in a way that adheres to the Occupational
Safety and Health Administration regulations.
l
Use only lifting equipment that can handle the full unit weight.
l
Only lift the unit by attaching the rigging to the four hoist rings on top
of the unit.
l
The minimum horizontal angle for lifting is 50 degrees.
l
The recommended way to lift the unit is to use a double A configuration
with a spreader bar.
Alternatively, use a quad Aconfiguration.
WARNING
Risk of serious injury or death!
Do not lift the unit using the trailer D-rings located on the side of trailer.
These D-rings are only to be used for securing the trailer, with the MPU
fitted, when it is transported using a flat-bed or goose-neck trailer.
Caution
Risk of damage!
Before lifting the unit, make sure the hoist eyelets are secured correctly to
the unit.
1 Safety information MP75-600 - User Manual
