MOXION MP75-600 - Electrical and Battery Specifications

74 of 82 MANUAL-75-v2.0
8.2 Electrical and battery specifications
Table 5 - Electrical specifications
Specification Values
Maximum power input AC power input:
l
19.2 kW via Level II EVSE Charger (SAE J1772)
DC power input:
l
40 kW via Level III EVSE Charger (SAE J1772 CCS Type 1)
Power Interfaces
l
Cam-locks (female, 1 set): 480Vac/3P, 208Vac/3P,
240Vac/1P
l
CS6369 twist-locks (female, 3 sets): 208Vac/3P,
240Vac/1P 50A
l
Edison duplex outlet (type B, NEMA 5-20R): 120V
Operating modes Standalone, serial hybrid configuration
Response time <50ms
Overload capabilities 120% overload for 100ms
Round trip efficiency Up to 95% (typical 88-95%)
Operating AC voltages 480Vac/3P, 208Vac/3P, 240Vac/1P, 120Vac/1P
Operating AC
frequencies
60Hz
Controls compatibility Generator Stop/Start
Table 6 - Battery specifications
Battery type Lithium-ion
Nameplate energy capacity 600kWh
Nameplate usable energy capacity 530kWh
MP75-600 - User Manual 8 Specifications
