MOXION MP75-600 - Mechanical Specifications; Transportation Specifications

76 of 82 MANUAL-75-v2.0
8.5 Mechanical specifications
Table 9 - Mechanical specifications
Specification Values
Dimensions MPU (L x W x H)
l
103" x 38" x 62" approx.
(262 cm by 96.5 cm by 157.48 cm)
MPU with trailer (L x W x H)
l
162.9” x 69.1” x 78.0”
(414cm by 176cm by 198cm)
Weight MPU with trailer (unit)
l
12500 lbs approx.
Tire size (front and rear) ST235/80 R16. Speed rating "L".
Tire pressure (front and rear - cold) 522 KPA (80 PSI)
Maximum tire load per tire 3520 lbs at 80 psi (cold)
8.6 Transportation specifications
Table 10 - Transportation specifications
Specification Details
Towing Class 5 pintle hitch and lunette ring for the trailer.
Lifting Four roof-mounted lifting eyelet sockets for overhead lift for the
MPU and the system.
Cargo Flat-deck trailer (road or rail).
Maximum towing
speed
Paved road: 55 mph
Off-road: 10 mph
MP75-600 - User Manual 8 Specifications
