MANUAL-75-v2.0 3
Contents
1 Safety information 7
1.1 Safety notices 7
1.2 Special safety instructions 8
1.2.1 Emergency stop button 9
1.3 Safety labels 9
1.4 PPE requirements 12
1.5 Safe operating area and clearance 12
1.6 Residual risks 13
1.6.1 Pinch points 13
1.6.2 Electrical current 14
1.6.3 Operating environment 15
1.6.4 Network and data security 15
1.6.5 Heat and flammable 15
1.6.6 Trip hazard 16
1.6.7 Heavy loads 16
1.6.8 Water ingress 16
1.7 Battery safety 17
1.7.1 Thermal runaway 18
1.8 Towing and transportation safety 18
1.8.1 Trailer registration 20
1.9 Lifting the unit 21
1.10 Personnel 23
1.10.1 Operating staff 23
1.10.2 Maintenance staff 23
1.11 Responsibility of the owner 23
1.11.1 Owner responsibilities 23
2 Hardware description 25
2.1 Overview 25
2.2 Dimensions 25
2.3 Main external parts 26
2.3.1 Main control panel 28
2.3.2 Outlet panel 29
2.3.3 Cam-lock connections 30
2.3.4 Twist-lock connections 31
