4 Operations
This section describes common tasks required for the operation of the MP75-600.
WARNING
Risk of serious injury or death!
Make sure you have read and understood all the safety information before
using this unit.
Only trained personnel are allowed to use and operate this unit.
4.1 Charging the unit
The unit can be charged using a standard electric vehicle supply equipment (EVSE)
with either a SAE J1772 plug or Combined Charging System (CCS) Type 1 plug.
Tip
The unit will not output high voltage when it reaches 3%.
The unit can be charged while it is running.
To recharge the unit, follow these steps:
1. Open the charge port door located on the left-hand side of the unit.
2. Plug in the charging connector.
l
Level 2 SAE J1772 (80A Limit)
l
Level 3 DC Fast Charging CCS Type 1 (100A Limit)
Tip
DC charging is possible only when the system is in STANDBY mode.
Notice
A Level 1 (120V) SAE J1772 charging connector is not compatible
with the unit.
3. After a plug is detected, the display shows Not Charging before proceeding to
Unit Charging and finally Charging .
4. The unit begins charging.
5. To confirm the unit is charging the charging icon is shown on the control display.
