MANUAL-75-v2.0 49 of 82
To attach the unit to a towing vehicle, follow these steps:
1. Remove the locking pin and lift the pintle hitch latch.
2. Position the pintle hitch directly under the lunette ring.
3. Using the tongue jack, lower the trailer and lunette ring coupler onto the pintle
hitch hook.
WARNING
Risk of crushing or trapped hands!
Stay clear of the pintle hitch and lunette ring as the tongue jack is
lowered.
4. Close and lock the pintle hitch latch and insert the latch pin.
5. Retract the tongue jack fully so that the full load of the trailer is taken by the
pintle hitch and towing vehicle.
6. Attach the trailer towing chains to the towing vehicle.
Cross over the chains and twist if there is any slack and may drag on the ground.
7. Attach the trailer 7-pin connector to the towing vehicle.
The 7-pin trailer cable contains both the trailer lights and trailer electric brakes.
8. Attach the emergency brake cable.
9. Start the towing vehicle engine and test the trailer brake and running lights.
10. Remove and stow wheel chocks.
You are now ready to start towing the unit.
4.3 Towing the unit
The unit is a large and heavy load. You should use an appropriate towing vehicle and
be familiar with towing loads of this type.
► For more information, see
Specifications
on page 73.
Notice
If the unit sustains any visual damage, such as cracks, dents, and so on, do
not turn on or use the unit.
Contact Moxion Power immediately for assistance.
Call 1-833-669-4661 or customersupport@moxionpower.com.
4 Operations MP75-600 - User Manual
