To connect twist-lock cables, follow these steps:
1. At the back of the unit, locate the bottom left panel door.
► For more information, see
Twist-lock connections
on page 31
2. If needed, unlock the panel door with the supplied keys, and then pull the latch to
open the door.
3. Open the cap of the twist-lock outlet.
Notice
The powering of the twist-lock connection depends on the voltage
output that you set for the unit.
► For more information, see
Turning on the unit
on page 38.
4. Insert your twist-lock cable, and rotate your twist-lock plug clockwise until it
stops to fully secure it.
Your twist-lock connections are now in place and ready to receive power from the
unit.
3.7 Running the unit
With the unit in
STANDBY
mode and cam-lock/twist-lock connections in place, you
can now set the unit to
RUN
mode to begin powering your load.
To run the unit, follow these steps:
1. At the back of the unit, locate the top right panel door.
► For more information, see
Control display
on page 34
2. If needed, unlock the panel door with the supplied keys, and then pull the latch to
open the door.
3. On the top right panel, switch the
Main Breaker
to the
ON
position.
4. Switch the
Twist Lock
breakers for the connected twist-lock cables to the
ON
position.
5. Turn the
Control
knob to the
RUN
position.
When the system starts running, the screen displays output power information,
for example, amperage, voltage, and power.
MP75-600 - User Manual 3 Quick start
