8 Specifications
This section details the specifications of the Moxion Power MP75-600.
8.1 Power specifications
Table 4 - Power specifications
Specification Output voltage types
Voltage 480Vac/3P 208Vac/3P 240Vac/1P
Voltage Tolerance (up to 5%) 456-504 Vac 197.6-218.4 Vac 228-252 Vac
Continuous rated power output 40kW 35kW 24kW
Maximum rated power (for 1 hour) 75 kW 35kW 24kW
Maximum phase current 100A 100A 100A
Maximum neutral current 100A 100A 100A
Power factor 1.0 1.0 1.0
Notice
The AC voltage is a 4-wire Wye configuration.
