Appendix 4 Specifications
Physical Specification
Temperature range: 0-45 °C (32-113 °F)
Humidity tolerance: 0% to 85% relative humidity, non-condensing
Dimensions Bolt X On
Pedestal
Bolt X On Track
Weight - Arm [kg] 560 560
Weight - Base [kg] 200 430
Weight - YRC1000 controller unit
[kg]
85 85
(included in the
weight of the
base)
Weight - anchor weights and wings
[kg]
1600 1600 (if taken
off the track)
Weight - floor plates (2 per section of
track) [kg]
NA 80 x 2
Maximum payload [kg] 20 20
Height - maximum lens height [mm] 4300 4300
Lowest position [mm] -1300 -1300
Maximum mechanical vertical
clearance needed [mm]
4800 4800
Maximum lens reach from rotate
centre [mm]
3212 3212
Maximum horizontal clearance
needed [mm]
3800 3800
Height - arm in transport position
[mm]
1719 1860
Length - arm in transport position
[mm]
1991 1112
Width - without wheels [mm] NA
Width - with wheels [mm] NA 1234
Width - with weights [mm] 2255 NA
Width - without weights [mm] 950 NA
