Bolt X Quick Start Guide
65
Ulti-box connector summary
The Ulti-box that is mounted on the Bolt X arm is a multi-purpose
interface box that is used to control servo motors on many MRMC heads
and Lens Control Motor (LCM) units. The Ulti-box offers versatile
connections for many camera and lens configurations although some of
the axes connectors such as PAN, TILT, and DATA are not ordinarily used
in the context of Bolt X, as Bolt X itself provides these features.
