At the Ultima Remote Sensor Location
1. Open the Ultima Remote Sensor cover by unscrewing it.
"!
WARNING
Before removing the cover of an explosion-proof Ultima
Remote Sensor, verify that the surrounding area does not
contain a flammable mixture of combustible gas and air
since a source of ignition is exposed; otherwise, an explosion
may occur if a metal object contacts the circuitry and
produces sparks.
2. Route the cable from the Ultima Gas Monitor through the
conduit opening and wire it to the terminal block in the
bottom of the sensor.
3. Verify the identity of each conductor of the cable and connect
the wire to the terminal block (FIGURE 1-23).
TERMINAL BLOCK LOCATION
3
2
1
If shielded wire is used, cut the shield wire short. Do not connect
the shield at the remote sensor.
4. Screw the conduit into the conduit opening and relieve any
excess slack in the cable.
5. Re-install the cover of the Ultima Remote Sensor.
Figure 1-23.
Catalytic Combustible Remote Sensor
Chapter 1, Set-up
1-21
