2. Route the cable from the Ultima Gas Monitor through the
conduit opening and wire it to the terminal block in the
bottom of the sensor.
3. Verify the identity of each conductor cable and connect the
wire to the terminal block (FIGURE 1-26).
For Toxics, there are no connections to positions 2 and 6 of
the terminal block within the remote sensor.
Do not connect the shield at the remote sensor.
4. Screw the conduit or cable grip or gland into the conduit
opening. Relieve any excess slack in the cable.
5. Re-install the Ultima Remote Sensor cover.
"!
WARNING
Do not let the cover remain off of an explosion-proof Ultima
Gas Sensor. Since a source of ignition is exposed, an
explosion may occur if a metal object contacts the circuitry
and produces sparks in an atmosphere of combustible gas.
Chapter 1, Set-up
1-26
