XR21S59 CHU 101
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
Opening the lift frame stowage lock
If the lift frame is in the XR21S hook (the liftframe has been picked up from
the immediate vicinity of the vehicle), continue to section ”Lifting the ISO
container”.
1. First rotate the middle sections of the ratchets enough to loosen them.
2. If needed, take the crowbar attached to the left side of the liftframe and
remove the dirt and ice from the areas where the ISO container and body are
attached.
The crowbar may also be used to extract the locking shaft. The locking shaft may
not be detached at this stage.
3. Turn the lock grips on the telescopic upper parts, on the surface of the lifting
frame’s vertical beams, into OPEN position (grips horizontally, images 3).
It is recommended to keep the lock grips in OPEN position when driving the truck
without an ISO container. The liftframe is then at its lowest.
4. Extract the locking shafts on the lower parts of the liftframe using the crowbar if
necessary. Turn the axis on both sides of the equipment to 180° temporary
STOWED position (lock plates vertical, images 4), note leave the whole pin
extracted so the liftframe can move in front of the stowage.
NOTE 1!
Leave the locking shaft into the temporary STOWED position only while you
remove the locking pin (phase 5), and then turn it into the STOWED position
(phase 7).
