XR21S59 CHU 156
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
1
2
3
4
5
1. Control unit in the cab
2. I/O module
3. Valve wiring harness
4. Accessory wiring harness
5. Wiring harness of proximity switches
Control devices, 2GCC
It is not allowed to make any
additional connections to
the electric system, wiring
harnesses and valve coils.
