Unloading phases
XR21S EQUIPMENT IS IN TRANSPORT POSITION WHEN STARTING MOVEMENTS
Unloading an ISO container
An ISO container can be unloaded in automatic mode A3, because the length of IC and
ICC ISO containers (6058 mm) doesn’t require movements in manual mode outside a
safe working area.
Only if the ISO container has a heavy load (more than 10 t) or its oor is extended,
should the beginning of unloading be done in manual mode A5 in order to prevent the
extended container oor from scraping against the XR21S equipment body.
The rst phases of unloading a heavy ISO container are depicted on the following pages.
