MULTILIFT XR S - Lowering the Tipping Device

XR21S59 CHU 61
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
A
M
CXXX / dXXX
>
Lowering the tipping device
12. Lower the tipping arm (middle
frame together with the rear frame)
- move the control lever forward
- stop the movement by releasing the
control lever.
12. Lower the tipping arm (middle
frame together with the rear
frame)
- move the control lever forward
- stop the movement by releasing
the control lever.
The main cylinders are released (oating) when the atrack/body is about 60 mm
above the body supports, and the nal stage of unloading is dampened.
13. Check that the frame of the XR21S equipment and the atrack/body are in the
lowest position.
14. Close the atrack/body tail gate.
15. Shut o󰀨 the oil supply of the hydraulic pump.
16. Check that all signal lights of the control unit have gone out.
MANUAL MODE A5AUTOMATIC MODE A2
Safety codes
