XR21S59 CHU 205
1/2018
113813003
Hooklift Multilift XR21S59 CHU
Service Manual
Sensors:
119 Middle frame down, Ø30 NO
120 Middle frame nearly down, Ø30 NO
313 Main cylinder protection, tilt indicator
316 Body locks open, Ø18 NO
317 Body locks closed, Ø18 NO
318 Rear frame down, Ø30 NO
319 Tipping lock closed, Ø30 NO
320 Hook arm back, Ø18 NO
321 Pull limiter, Ø18 NO
114 Stowage in, Ø18 NO
115 Stowage out, Ø18 NO
125.1 Ratchet left, Ø18 NO
125.2 Ratchet right, Ø18 NO
126 Liftframe on the stowage, Ø30 NO
LUBRICATION
Lubricate all the lubrication points at max 3 month intervals. A more recommended lubrication
interval would be 1 month.
Note! The hooklift equipment contains plastic surface slide bearings.
Use LITHIUM based general lubrication grease (EP2).
Molybden based lubricant shortens the service life of the bearings.
If the hooklift is equipped with a central lubrication system, this will need to be checked
according to the manufacturer’s instructions.
Lubrication points >>>
