XR21S59 CHU 55
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
CXXX / dXXX
>>>>
A
M
Tipping a atrack/body
XR21S -EQUIPMENT IN TRANSPORT POSITION, STARTING MOVEMENTS
1. See the safety instructions before tipping.
THE XR21S SHOULD NEVER BE USED TO TIP AN ISO CONTAINER
2. Drive the truck to the place where the load has to be discharged.
3. Engage the parking brake.
4. Engage the hydraulic pump.
Safety codes
5. Select automatic mode A2
- push the A2 button approx 2 s.
5. Choose manual mode A5
- push the A5 button for approx. 2 s.
MANUAL MODE A5AUTOMATIC MODE A2
6. Open the atrack/body tail gate
- note the atrack/body operating instructions
- stand by the side of the atrack/body so that the opening tail gate and discharging
load do not hit you.
