XR21S59 CHU 135
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
!
A
Releasing the liftframe from the ISO container
LIFTFRAME ATTACHED TO AN ISO CONTAINER DURING UNLOADING
WHEN STARTING MOVEMENTS
Let the engine run at idle speed during stowage movements.
NOTE!
Unnecessary use of the main pressure relief valve
should be avoided, because it may overheat the oil.
1. Opening the locking shafts on the lower corners and lock grips on the upper
parts of the liftframe
1. Release the lower liftframe corners from the ISO container by extracting the
locking shafts using the crowbar if necessary.
Turn the shafts on both sides of the equipment to 90° upward, and fasten them
again to the body, the locking plates in a STOWED postion.
2. Turn the lock grips on the telescopic upper parts of the liftframe back to
open position (grips horizontally).
2. Lifting the upper part of the liftframe from a container
PHASES SHOULD BE CARRIED OUT IN AUTOMATIC MODE A3
1. Select automatic mode A3
- push the A3 button approx 2 s.
2. Small movement middle frame forward
- “locks not closed”, ”URB” and ”frame not down” signal lights on the control
unit are lit
- move the control lever momentarily to the front.
Drive the middle frame a little bit forward, in order to lift the liftframe from the
ISO container corner boxes.
