XR21S59 CHU 65
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
A
M
CXXX / dXXX
>>>>>
Unloading a atrack/body
XR21S -EQUIPMENT IN TRANSPORT POSITION, STARTING MOVEMENTS
1. See the safety instructions before unloading.
2. Drive the truck to the place where the atrack/body has to be unloaded.
3. Check the working area
- ensure that there is enough space in front, rear and above the truck.
4. Engage the parking brake.
5. Engage the hydraulic pump.
6. Choose manual mode A5
- push the A5 button for approx. 2 s.
6. Choose automatic mode A1
- push the A1 button for approx. 2 s.
MANUAL MODE A5AUTOMATIC MODE A1
Safety codes
7. If it seems impossible to select the mode and code ”d019” is displayed on the
control unit, make sure that the attachment joints of the liftframe ratchets
are attached to the stowage.
