XR21S59 CHU 89
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
A
M
Fetching the liftframe with the XR21S hook, moving
it and locking it to the stowage
XR21S EQUIPMENT IS IN TRANSPORT POSITION WHEN STARTING MOVEMENTS
During atrack/body change the horizontal movement is in atrack home position (approx.
350 mm behind the stow/unstow position).
The recommended pump running speed is between 1000 - 1400 k/min. Let the engine run
at idle speed at the beginning and end of movements and when using the locks.
1. Reverse the truck carefully close to the liftframe.
Stop it about 5 meters from the liftframe gripping bar.
2. Engage the parking brake.
3. Engage the hydraulic pump.
4 Choose manual mode A5
- push the A5 button for approx. 2 s.
4 Choose automatic mode A1
- push the A1 button for approx. 2 s.
MANUAL MODE A5AUTOMATIC MODE A1
5A. If it seems impossible to select the mode and code ”d019” is displayed on the
control unit, make sure that the attachment joints of the liftframe ratchets
are attached to the stowage.
