XR21S59 CHU 151
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
!
! !
Tipping an ISO container IS NOT allowed!
THE XR21S REAR ROLLERS WERE NOT DESIGNED FOR
TIPPING AN ISO CONTAINER.
THE ISO CONTAINER SUPPORT ROLLER AXIS AND THE XR21S
TIPPING AXIS ARE NOT IN LINE WITH EACH OTHER. AS A RESULT, TIPPING IS
NOT POSSIBLE.
Always drive in trac with the middle frame
lowered onto the sub frame.
