9. Middle frame forward
- drive the middle frame forward by holding the control lever in the front (main
cylinders in)
- “frame not down” signal light on the control unit goes out, when the middle frame
comes down.
10. Horizontal movement forward
- drive the horizontal movement forward by pushing the front button in the
bottom row on the either side of the control unit (telescope cylinder out)
- horizontal movement comes to the atrack home position
(approx. 350 mm from the stow/unstow position of horizontal movement).
11. Closing body and tipping locks
- logic closes the body and tipping locks automatically as the control unit is
released at the end of the horizontal movement
- when the locks are engaged fully, their signal light will go out.
12. Shut o the oil supply of the hydraulic pump.
13. Check that all signal lights of the control unit have gone out.
You are now ready to pick up your next container.
