XR21S59 CHU 149
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
M
!
No maintenance work may be carried out
on a liftframe supported by stand supports!
8. Free from the liftframe
Manual mode A5 is selected.
8.1. Open the hook safety lock by pressing its release button.
Make sure that the lock opens.
If it doesn’t lift the middle frame slightly by moving the control lever
forward. Open the safety lock.
8.2. Keep the safety lock button pressed and drive the middle frame slightly
backwards by moving the control lever backwards. Monitor the hook being
released from the gripping bar on the liftframe.
DO NOT TIP THE LIFTFRAME OVER!
8.3. Drive the truck forward if the hook has been released from the gripping bar.
Release the safety lock button. The lock will close in 10 s. Activate the handbrake.
