Buttons on the stowage control unit
The emergency stop switch of the equipment
(e󰀨ects all XR21S equipment functions, and demountable and ISO container handling)
- pressing the emergency stop switch will stop the movement of the XR21S
equipment at any time.
- when the dangerous situation causing the emergency stop has passed, work
can continued by releasing the emergency stop switch back to the operation
position.
The UNSTOW and STOW buttons on the control unit
Press the UNSTOW button without releasing it:
- 1: body locks open if they are still closed
- 2: horizontal movement moves to the stow/unstow position
- 3: the stowage actuator turns the stowage hook up and lifts the liftframe from
the stowage to the XR21S gripping hook
- 4: the safety lock of the XR21S gripping hook locks the liftframe to the
gripping hook of the equipment
- 5: the stowage actuator turns the stowage hook down
Press the STOW button without releasing it:
- 1: body locks open if they are still closed
- 2: the stowage actuator turns the stowage hook up and lifts the liftframe from
the XR21S gripping hook
- 3: the safety lock of the XR21S gripping hook opens and remains so, until the
stowage hook has returned to the down position
- 4: the stowage actuator turns its hook down and brings the liftframe onto the
stowage
- 5: horizontal movement goes to the atrack home position (approx. 350 mm from
the stow/unstow position of horizontal movement).
