XR21S59 CHU 86
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
Stowage control unit
Button STOW Button UNSTOW
The XR21S emergency stop switch
(stops the handling functions of a demountable and an ISO
container)
1 2 3 4 5
UNSTOW pushed down
STOW pushed down
1 2 3 4 5
UNSTOW / STOW phases
Signal light ”POWER ON”
The light is lit when the stowage mode (A4)
or the manual mode (A5) is selected.
