Hooklift Multilift XR21S59 CHU
User Manual
During transport of ISO-containers the lift frame must always be locked at the
front by the 2 ratchets mounted to the stowage. Because an ISO-container locked
at all four corner castings is limiting the exibility of the chassis, and can cause
high stresses in ratchets and twistlocks, o road driving with an ISO-container
must be performed at low speed.
23. Locking a container to the XR21S equipment (must ALWAYS be locked before
driving)
1. In the front the container is attached by adjustable ratchets in the liftframe.
Detach the ratchet ends from the stowage and attach them to the attachment
brackets on both sides of the liftframe with the shafts there. Push the shafts
into the brackets from the sub frame side and put the linch pins in from the
outside. The length of the ratchets can be adjusted by rotating the middle
section with internal threads enough for the pins in the ratchet attachment joints
to go into place. Prevent the free end of the ratchet from rotating along with the
middle section. Tighten the middle sections of the container ratchets by rotating
them while the ends are attached to the attachment joints.
If the container was loaded on uneven ground, drive the truck carefully
to even ground and if necessary, center the front of the container by tightening the
ratchets.
2. Tighten the back of the container with TWISTLOCKS.
Push the tightening wheel of the locks upwards, so that the clasp is pushed into
the corner box of the container. When the tightening wheel is turned clockwise,
the clasp rst turns into a horizontal position and then as the wheel is turned
more, engages the lock.
21. Shut o the oil supply of the hydraulic pump.
22. Check that all signal lights of the control unit have gone out.
