XR21S59 CHU 103
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
5. Disconnect the right ratchet from the liftframe and place it temporarily on the
suspension hook on the stowage.
6. Move the bottom part of the liftframe back while rotating the middle section of the
LH ratchet long enough to have the locking shafts behind the attachment joints of
the stowage.
7. Turn the locking shafts on the bottom parts of the liftframe to their STOWED
position (locking plates vertically).
8. Disconnect the left ratchet and temporarily place it on the stowage suspension hook
so that the ratchet locking pins are in place (locking position).
NOTE 2!
After releasing the locking shafts and pins, the liftframe will lurch towards the
cockpit of the vehicle. MIND your hands!
Proceed to control the equipment with the stowage control box buttons.
