XR21S59 CHU 107
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
5 Pushing the liftframe in the hook
Code ”A4” is displayed on the XR21S equipment control unit display is lit.
Green signal light ”power on” on the stowage control unit is lit.
Push the UNSTOW button on the stowage control unit without releasing it:
5.1 Opening body locks
The body locks open if they are still closed.
5.2 The horizontal movement goes in the stow/unstow position
Starting from Flatrack position (350 mm behind the stow/unstow position).
