5.3 Lifting the liftframe onto the gripping hook of the XR21S equipment
The stowage actuator turns the stowage hook up and lifts the liftframe from
the stowage onto the XR21S gripping hook
5.4 Closing the safety lock of the XR21S gripping hook
The safety lock of the XR21S gripping hook locks the liftframe to the
gripping hook of the equipment
5.5 The stowage hook turning downwards
The stowage actuator turns the stowage hook down
