Hooklift Multilift XR21S59 CHU
User Manual
M
A
1. See the safety instructions before loading.
2. Reverse the truck to about 5 meters from the container.
Check the safety of the working area.
3. Activate the handbrake.
4. Engage the hydraulic pump.
5. Horizontal movement out (only in manual mode A5).
1. Choose manual mode A5, push the A5 button for approx. 2 s.
- code ”A5” is lit on the XR21S equipment control unit display
- green signal light ”power on” is lit on the stowage control unit.
2. Open the body locks
- push the ”bodylocks open” button
- “the “locks not closed” signal light on the control unit is lit, when the locks are
open.
3. Drive the horizontal movement cylinder in
- push the rearmost button in the bottom row on the either side of the control
unit, until the horizontal movement goes to the atrack home position
(approx. 350 mm from the stow/unstow position of horizontal movement).
AUTOMATIC MODE A3
6. Select automatic mode A3
- push the A3 button approx 2 s
- “power on” signal light on the stowage control unit goes out.
7. Opening body locks
- move the control lever slowly backwards
- under-run bar is retracted, if it is not in
- URB signal light on the control unit is lit, when the under-run bar is in the in
position
- the system attempts to open the body locks
- “locks not closed” signal light on the control unit is lit, when the locks are fully
open.
