Monitor the lower ends of the liftframe during the movement.
If the body is in danger of colliding with the rear rollers, stop the
movement before colliding and continue according to sections
10A and 10B.
8. Horizontal movement into rear position
- keep the control lever in rear position
- horizontal movement slides backwards (cylinder in)
- mechanical tipping lock opens when the hook frame is in rear position.
9. Middle frame back
- keep the control lever in rear position
- middle frame turns back (main cylinders out)
 -”framenotdown”signallightislit,whenthemiddleframeisliftedothe
subframe.
Stop the movement by releasing the control lever, when the container locking pins
on the telescopic upper sides of the liftframe are a little above the containers
upper corners.
10A. Driving the horizontal movement outwards
(only in manual mode A5).
1. Choose manual mode A5, push the A5 button for approx. 2 s.
- green signal light ”power on” is lit on the stowage control unit.
2. Drive the horizontal movement cylinder out
- by pushing the front button in the bottom row on the either side of the control
unit, in order to avoid the risk of a collision.
