Hooklift Multilift XR21S59 CHU
User Manual
M
A
A
10B1. Driving the middle frame backwards
- Continue the middle frame movement by moving the control lever
backwards, enough to prevent a collision.
10B2. Change to automatic mode in the end by selecting mode A3
- “power on” signal light on the stowage control unit goes out.
Perform the middle frame movement to just above the upper corners of the
container, as explained in section 9.
11. If needed, move the truck sideways or lengthwise, until the control anges of the
telescopic upper sides of the liftframe are beside the upper corner boxes of the
container and the container locking pins are next to the container corner box
openings.
The truck and the ISO container must be exactly parallel.
12. Liftframe attached to ISO container 1
1. Reverse the truck so that the control anges on the lower parts of the liftframe
move along the exterior of the lower container corner boxes to the sides of the
container. Continue reversing until the lower part of the liftframe comes
against the container.
2. Continue in automatic mode A3.
- move the control lever into rear position in order to lower the liftframe
further and to get the container locking pins on its telescopic upper parts into
the container corner box openings. Continue the movement downwards.
Stop the movement by releasing the control lever when the lower ends of the
liftframe reach the ground.
