Hooklift Multilift XR21S59 CHU
User Manual
!
13. Liftframe attached to the ISO container 2
1. Turn the locking shafts on the lower parts of the liftframe on both sides of
the equipment 90° downward from their STOWED postion to their LOCKED
position into the container.
2. Turn the lock grips on the telescopic upper parts of the liftframe back to
locked position (grips vertically).
3. Check before loading, that the TWISTLOCK clasps are inside the lock
mechanisms.
The TWISTLOCK clasp protruding from the lock mechanism grips the lower
structures of the loaded container damaging them and a clasp gripping only one
side of the container may cause the truck to fall over as the haul is continued.
14. Loading an ISO container on a truck
Follow the instructions in section Loading a atrack/body, when loading a sea
container onto the XR21S equipment.
