MULTILIFT XR S - Page 141

XR21S59 CHU 141
1/2018
113813003
Hooklift Multilift XR21S59 CHU
User Manual
!
>>>
The safety lock of the XR21S gripping hook is in open position
during stowage movements, which may cause the frame to fall
o󰀨 if the stowage bumps into the liftframe.
5.3 Lifting the liftframe from the XR21S gripping hook
The stowage actuator turns the stowage hook up and lifts the liftframe to
the top of the XR21S gripping hook opening
5.4 Opening the safety lock of the XR21S gripping hook
The liftframe comes free of the XR21S gripping hook
5.5 The stowage hook turning downwards
The stowage actuator turns its hook down and brings the liftframe onto the
stowage.
The safety lock of the XR21S gripping hook closes as the STOW button is
released.
5.5a Code ”d025” is displayed if ”Stowage in” sensor is active, but ”Lift Frame
Stowed” sensor is not active.
It will also prevent sliding backwards movement.
5.6 The horizontal movement goes back to the container changing position
horizontal movement goes to the front position of container change (approx.
350 mm from the far-front position of horizontal movement).
6. Shut o󰀨 the oil supply of the hydraulic pump.
7. Check that all signal lights of the control unit have gone out.
